Topic: For GM 2018 2019 Diagnostic Programming，VXDIAG VCX NANO GM or GM Tech2  or GM MDI?





One comparison table among VXDIAG VCX NANO GM, GM Tech2 & GM MDI:



Item	VXDIAG VCX NANO for GM/Opel	GM MDI WIFI	GM Tech II scanner
Software	GDS2 (2014) /Tech2Win	GDS 2 (2011)Tech2 Win	TIS2000/SPS
Need computer	Yes, it's PC-based.	Yes, it's PC-based.	TIS2000 on WinXP
System requirement	Win7 32/64bit /Win8 64bit system	Package software: Win XP only   v2016.11 software: Win 7	Win XP for TIS2000
Multi-Language	Multi-Language	Multi-Language	Multi-Language(depends on vehicles)
WIFI	YES, VXDIAG GM has wifi version and USB version	WIFI and USB connection	NO
Diagnosis	wireless basic diagnostic	wireless basic diagnostic	basic diagnosis
Programming	GM TIS2WEB online Service Programming System (SPS)	wireless online programming   –offline programming ,such as European Chevrolet, Opel, but not for all cars	Online programming with TIS2000 on Saab/Opel (-2008)
Update	Firmware updatable Software updatable	Firmware update	Update via 32MB Card
Activation	No need to activate	Yes, MDI need activation.	No need to activate
Supported protocols	CAN, UART, KW2000, Class2, GM LAN, etc.	UART, Class 2, KWP2000 and GMLAN (CAN)	CANdi interface
Supported vehicles	Vehicles to 2015 GM, OPEL	vehicles from 1990-2014 GM, Opel, Chevrolet, Saab, Australia Holden (2010-2012)	vehicles from 1992-2013 GM, SAAB, OPEL, UZUKI, ISUZU, Holden
Advantage	-cheap but with the same function as GM MDI   – WIFI and USB connection -good for new cars	-can support software from original factory -support offline & online programming	-cannot plug original software card, but can support original program   -easy to carry on

As you can see, GM MDI is the best GM 2009 - 2019 diagnostic and programming tool.

It is cheap (238eur with software and free delivery).

It is programming online, support offline programming for Opel Chevrolet.

If you want to program by using GM MDI, you need to buy account at GM MDI official site:

https://www.acdelcotds.com/acdelco/action/subscribehome



GM MDI Compatibility:

Device is compatible with GDS2 (Opel)

Device is compatible with Tech2Win (Opel, Hammer)

Device is not compatible with SAAB via Tech2Win



GM MDI Cars test reports yes and no:

1: SAAB 9-5, 2003, 3.0 TID- Yes

mine is clone from China.

MDI Software 8.1.135.13

GT32

SAAB NAO V9.250

Simply pressed OK when Candy detected and all worked.

Tested on SAAB 9-5, 2003, 3.0 TID



2: 2014 model - Yes

SAAB NAO V9.250 is from 2014. Already tested.

2003 year too old - not interesting for me.



3: Saab 9-5, 2003, 3.0 - Yes

Tested by my own, works with Saab 9-5, 2003, 3.0

1: online - good, offline - bad

GM MDI good, interface works online.

update mdi 100%.

offline too bad for new cars.



2: wifi card compatible

So far, Chinese clone GM MDI with squ wifi card



3: wifi is not working but works fine with USB

I bought a cheap one and it only worked with usb. The wired network and wifi did not work. In fact, the card flash socket was missing from the board. Build quality was not to bad. I just use it to flash newer pcm/ecm's.



GM MDI WIFI version:

http://www.obdexpress.co.uk/wholesale/gm-tech2-gm-diagnostic-scanner-obd2express.html

GM MDI USB version:

http://www.obdexpress.co.uk/wholesale/gm-mdi-multiple-diagnostic-interface-with-usb-connection.html



Part 2: Why GM MDI instead of Tech II scanner?

Flash faster: MDI & GDS2

As for why GM is going to the GM MDI and GDS2, instead of using a Tech II with TIS2000 software, because the MDI with GDS2 flashes a hell of lot faster when you have flash a new module with either it orginal firmware or upgraded firmware. Its also faster to use than having to press buttons on the Tech II for basic commands during diagnostics as well.



Older cars: Tech II & TIS2000

So in regards to the vets, Tech II clone will cover all the C6 cars and older since the last of the updated firmware on the unit covers from here back. If you do need to reflash something, it's done via Tis2000 with the Tech II as the pass through device.



New & old cars: MDI interface

Since GM did not make upgraded firmware to flash into the Tech II's to cover these cars like C7, then it's a MDI that is needed instead. As for the MDI's firmware, they will cover not only the new cars, but the cars that the old Tech II's used to cover as well.



Now the glitch on the MDI regarding cloning it, since it has to use the GDS2 software for the pass through only device, GDS2 software has not been cracked like Tis2000 software has been instead.



GM account for subscription: MDI need it

So the only way that even a clone MDI is going to work, is to have a subscription to GM (Few $K a year) to allow you to use the GDS2 software that has to log into GM each time it used instead.



Hence the Clone Tech II unit you get will already be loaded with the most current firmware, and for most of the stuff you going to use the Tech II clone, will just be using the unit by itself without being connected to a laptop.



Also the cracked copy of Tis2000 that you get with the clone model, does not have to be connected/logged into GM to use it for 99% of the stuff (do not need an account with GM).

Note, if push comes to shove and you can not find a copy of the needed firmware to flash into a unit to upgrade a module, then you can get a one day subscription to GM to pull down the needed file from them.



Part 3: GM MDI alternative: VXDIAG VCX NANO GM device

Confirmed: VXDIAG VCX NANO GM device works as a clone to the GM MDI.

since it also comes with GDS2 as well to work on newer cars.



I ordered and received a VXDiag VCX Nano on Saturday. I currently have a Tech 2 clone unit.

I primarily bought it for the later cars which use GDS2/MDI, specifically a Chevy Cruze and a '15 C7. I also bought a refurbished HP Elitebook running Windows 7 Pro 64-bit on a dual core I5 processor.



The software CD that comes with the VCX Nano I received has two install routines with installation instructions that were brief and somewhat minimal. One install routine for Tech2Win and one for GDS2. The Tech2Win software installs and runs under native Win 7, and with not too much trouble that was up and running, and I could use it on an '01 Vette.



Install the VM player as admin (right click on it and select run as admin).

Once have vm player installed on your machine, forget all about the VM player app start icon, since you not going to use it, since the xp version it has set up under it, will not work with nothing else but GDS2.

Now copy the GDS2 folder from the disc, to somewhere on your drive (folder and the files in it).

Now in that GDS2 folder you just copied to your hard drive, your going to right click on the VM.vmx file inside that folder and select to open it with Vm player app (selected from programs from the list).

If you want a icon to click on to open the GDS2 program via VM player without having to go into the folder each time, do a copy on the VM.vmx file via the right click method, go over to your desk top, do a right click paste of it there to make a short cut, do another click on the shortcut icon you just pasted into desk top, go down to rename, and just change the shortcut name to GSD2. Now when you click on the new icon named GSD2 you just made, it will open up GDS2 in the vm player.

If you want the icon in the start drop down menu, then right click on it again, and select pin to start menu (classic in my case, since I run classic shell since windows 8).

Hence you don't start the GDS2 program by clicking on VM player, but by clicking on the vm.vmx file in the program, with it desinated to be opened up via VM player instead. Note if you do the GDS2 shortcut icon, make sure that is selected to open up with VM player as well.



Cons:

Someone think it sounds like the Nano is not an option for us novice users, Seems like a very difficult process.



Sum:GM MDI and VXDIAG VCX NANO for GM is the top choice for GM Opel Saab up to 2018 2019 diagnostic and programming. GM Tech2 clone for GM up to 2009 year.
