How-to guide of where to download TMPro 2 key programmer Software and how install&update:
1.TMPro software download and install:


Download link: http://tmpro2.com/sw/TMPro2_software.zip and unarchive in any folder.

2.USB driver software download and install:



connect TMPro hardware and:
For Windows 7/8/10 users:

Windows will installs driver automatically.
For Windows XP and some Windows 7 users:

if Windows asks for drivers

TMPR2 driver software download link: http://www.tmpro2.com/sw/TMPro2_drivers.zip



After drivers are installed successfully start TMPro2.exe software. If everything is OK, in left down corner of software you have to see message: No file loaded. Your TMPro programmer is ready for use.
TMPro programmer can be installed on unlimited number of computers.

If you run TMPro software BEFORE installing of programmer, you may face this error: “Program cannot start because FTD2XX.dll is missing”.

If in left down corner of software you see message “Hardware NOT found“, this means that something with driver instalation is wrong. Restart computer and try again with drivers installation.

NOTE 1 – about upgrading your box to new design with red antenna:

If your TMPro box is with white antenna and round 8-pin connector

you can easy upgrade it to new design with red antenna

You must have a box upgrade set



NOTE 2 –

For owners of older TMPro hardware without round 8-pin connector

If you wish to upgrade your hardware for to use full functionality, you must have the hardware upgrade set



Good to know:

TMPro2 works with immobilisers eeprom dumps.

You must have electronic knowledges and to know how to use soldering-desoldering tools and memory devices programmers. It is your choice what programmer you will use for reading memory devices – TMPro2 memory device programmer or other progarmmer. In order to program transponder you have to remove immo box/BSI/UCH unit from car, open it, desolder memory device or solder wires on testpoints, and read it. Depending of vehicle memory device can be serial eeprom, Motorola MCU, Microchip PIC MCU, ST10F269 MCU, Texas Instruments MCU etc… Next step is to program transponder. Last step is to solder back memory device, reassemble immobox/BSI/UCH and fit back to car.

Working with TMPro2 is easy. You must have some electronic knowledge and equipment, like soldering iron, hot air gun, multimeter etc. Also you need to know which unit contains key data, and it`s location in vehicle. Remove unit from vehicle, open it and locate memory device. For some of units memory device is easy to be accessed, but for other it is not easy – you must cut a hole, dig a silicone etc.

When type of memory device is clear, you have to see how you can read/write it.

For 70% software reading and writing of memory devices, it can be done either by TMPro2 or by other programmer.

For 5% software reading and writing, it’s a must to be made with TMPro2.

For 25% software reading and writing of memory devices, you must use other programmer.



Memory device depends on the unit, that contains key data.



Memory device can be:
* Serial eeprom. Supported are all 93cXX, 24cXX, 25/95cXXX, X5328, S29190, X24c01, 95p08.To read or write serial eeproms, you must desolder it from board and solder on TMPro2 eeprom adapter. On adapter there are sockets for 3 different types – DIL, SMD and SSOP.

* Motorola 912/9S12 not locked, ST10F269 or Moric. To read or write these MCU you have to use cable with 8 stripped wires. Solder wires according to connection diagram for particular software.

* Motorola HC805P18. To read or write this Motorola you must use TMPro2 Motorola HC805P18 adapter. Desolder MCU from immobox and solder it on adapter.

* Microchip PIC. To read or write Microchip PIC you must use TMPro2 PIC adapter. Solder wires according to connection diagram for particular software.

To connect adapters to TMPro2 box you must use cable for adapters.

* Motorola HC05/HC908/HC11, Motorola 9S12 locked, flash chip, TMS370C702. To read or write these memory devices you have to use other programmer.

NOTE:Microchip PIC adapter, eeprom adapter, cable with 8 stripped wires and cable for adapters are included in basic set of TMPro2.

NOTE:Motorola HC805P18 adapter is not included in basic set of TMPro2. You can buy it along with basic set or at later time.

After all connections are done, you have to press on Select and read memory device button, select correct memory device and press OK to process with reading. After reading is done if you wish you can save file read for your archive.

In case for to read and write memory devices you use other programmer, then after memory device is read and file is saved by your programmer you have to load this file in TMPro2 by clicking on Open file button.



TMPro2 Tech Support: http://www.obdexpress.co.uk/



This week with lonsdor k518ise, all keys Europe:


Fiat 500 spare key:
after market remote, pre coded remote and chip, pincode read and key programming- success.


Opel vivaro 2012 all keys lost:
Used renault trafic option.pincode bypass. Success.


Opel corsa d All keys lost:
Read pincode, programme key, success.


Freelander 2 2009 spare key:
Success


Ford kuga 2016 all keys lost:
smart key ID47. Success


Audi a3 2004 spare key:
read pincode fail, used supervag


Ford focus 2007 all keys lost:
Success.


Ford transit 2008 spare key:
Success.


Hyundai i30 2012 spare key:
read pincode fail (used kdx2 for pincode) programme key success.


Hope this helps




Attach: Lonsdor K518ise European Car List
Audi, BMW, Benz, VW, Volvo, Citroen, Ferrari, Maserati, Fiat, Lamborghini, Jaguar, MG,
Land Rover, Bentley, Lancia, Opel, Peugeot, Porsche, DS, Renault, Alfa Romeo, Smart,
Borgward


Use "Ctrl+F" to seach quickly

Series	Origin	Year	Fuel Type	Function
2937	Immobiliser System	Thesis	02-09	Key Programming
2938	Immobiliser System	Ypsilon	03-06	Key Programming
2939	Immobiliser System	Phedra	05-	Key Programming

ALFA ROMEO

Series	Origin	Year	Fuel Type	Function
2930	Immobiliser System	159	Other	Key Programming
2931	Immobiliser System	Spider	Other	Key Programming
2932	Immobiliser System	Brera	Other	Key Programming
2933	Immobiliser System	147	Other	Key Programming
2934	Immobiliser System	GT	Other	Key Programming
2935	Immobiliser System	Giulietta	Other	Key Programming
2936	Immobiliser System	Mito	Other	Key Programming

KNOW BEANS

Series	Origin	Year	Fuel Type	Function
2884	ZD2	Other	Other	Other

OPEL

Series	Origin	Year	Fuel Type	Function
Read PIN code	Other	Other	Other	Type 1
Immobilizer System	Select from type	Type 1	Other	Smart Key
Immobilizer System	Select from vehicle	Insignia	Other	Smart Key
Immobilizer System	Select from type	Type 1	Other	Immobilization
Immobilizer System	Select from vehicle	Insignia	Other	Immobilization
Immobilizer System	Select from type	Type 2	Other	IMMO2
Immobilizer System	Select from vehicle	Agila	Other	IMMO2
Immobilizer System	Select from vehicle	Astra-G	Other	IMMO2
Immobilizer System	Select from vehicle	Calibra	OtherIMMO2	IMMO2
Immobilizer System	Select from vehicle	Combo	Other	IMMO2
Immobilizer System	Select from vehicle	Corsa-B	Other	IMMO2
Immobilizer System	Select from vehicle	Corsa-C	Other	IMMO2
Immobilizer System	Select from vehicle	Meriva	Other	IMMO2
Immobiliser System	Select from vehicle	Movano	Other	IMMO2
Immobiliser System	Select from vehicle	Omega-B	Other	IMMO2
Immobilizer System	Select from vehicle	Sintra	Other	IMMO2
Immobiliser System	Select from vehicle	Tigra-B	Other	IMMO2
Immobiliser System	Select from vehicle	Vectra-B	Other	IMMO2
Immobilizer System	Select from vehicle	Zafira-B	Other	IMMO2
Immobiliser System	Select from type	Type 3	Other	IMMO3
Select from vehicle	Astra-H	Other	Type 3
Immobilizer System	Select from type	Type 4	Other	IMMO4
Immobilizer System	Select from vehicle	Agila B	-2009	IMMO4
Immobilizer System	Select from type	Type 5	Other	IMMO5
Immobilizer System	Select from vehicle	Agila B	2009-	IMMO5
Remote control System	Astra-H	Other	Other	Remote control
Remote control System	Zafira-B	Other	Other	Remote control
Remote control System	Vectra-C/Signum	Other	Other	Remote control
Remote control System	Corsa-D	Other	Other	Remote control

SHIGAOKA QUEEN

Series	Origin	Year	Fuel Type	Function
Immobiliser System	Other	Other	Other	Type 1

FIAT

Series	Origin	Year	Fuel Type	Function
Viaggio	Other	Other	Other	Key Programming
Palio	Other	Other	Other	Key Programming
Siena	Other	Other	Other	Key Programming
Bravo	Other	Other	Other	Key Programming
Perla	Other	Other	Other	Key Programming
Freemont	Other	Other	Other	Smart Key Programming
Viaggio	Other	Other	Other	Smart Key Programming

  For more european car list, pls go to:


http://blog.obdexpress.co.uk/2018/11/16/review-lonsdor-k518ise-and-european-cars/
